Special features:
Learn: When the feed arm is aligned with the pattern machine, press this key, and then press
the key to move the feed arm to the needle center of the pattern machine. If it over-travels,
press the key to move it back. After it is well aligned, press the OK key. The feeding distance
can be automatically adjusted fast.
2. Compensation: As there are different materials, the cut material may be inconsistent with
the input parameters. Press the Compensation key, and input the cut size; the machine will
adjust the length automatically.
3. Air cylinder pressing: the air cylinder pressing mode is adopted. When the material is feeding,
Because the material will curl, the air cylinder will automatically hold the material when the
material is delivered in place, so that the material will not move. (patented products)
4. Blowing: Blow down when cutting the belt, so that the material will not warp up, which is
convenient for the machine arm to press the material.
5. Feeder arm: adopts stepping motor for feeding, with fast feeding speed, high feeding accuracy,
low noise and fast adjustment of feeding distance. (patented products)
6. Adjustable presser foot width: just loosen the lefy and right fixing screws on the presser foot,
move back and forth according to the actual width, and tighten the screws, which is convenient
and fast.
7. Interchange of knife die and cutter die: The right-angle blade can be directly replaced with a
cutter die for cutting round corners as required.
8. The whole machine integrated design: It adopts mechanical and electric control integrated
design, with small overall volume, simple wiring and convenient installation.
9. Multiple security protection.
Applications:
The round, right and different angles can be sewn by replacing the cutter die, so that a wide
range of applications, high feeding speed and user-friendly adjustment can be achieved.
The material can be fed into the slot with the Velcro, which is not easy to fall out. It is widely
used in the factories of reflective clothing, luggage, carpets, jackets, tents and so on.
